Product Details
Heartland Steel Safety Rails
- Bright OSHA yellow finish on columns.
- Meets OSHA safety rail requirements.
Additional specifications:
- Rails are 11ga high-tensile steel formed into a two-rib corrugated design with two secondary ribs.
- Lift-out rail available for quick access to equipment.
Heavy-Duty Industrial Guardrail Specifications and Features:
- Simple layout with universal column, designed to AISC specifications.
- Easy installation with all hardware included and painted with bright, OSHA yellow powder coat finish.
- 10,000-pound load at 4 miles per hour rating.
- Triple, double, and single rail applications available.
- Lift out rail available for quick access to equipment.
- Rails available in lengths starting at 3 feet through 10 feet long.
- Anchors are, 5-1/2-inch screw anchors and hardware are A325 1/2 inch.
- Columns are 4 x 4-inch square tube manufactured from high strength steel.
- Baseplate is 10 x 10-inch square x 5/8-inch-thick steel and can be offset if needed.
- Rails are 10 gauge high-tensile steel formed into a two-rib corrugated design with two secondary ribs.
Standard Products:
Special lengths are available
Warranty Information
Product Warranty
1-Year Manufacturer's Warranty
Heartland Steel Products warrants its products to be free of defects in material and workmanship and according to agreed specifications and for ordinary applications for which they were designed. This warranty shall extend for a period of ONE YEAR from the date of shipment. This warranty does not apply to parts that, through normal use, require replacement during the warranty period. Seller's liability under warranty shall be limited to repair or replacement of MATERIALS ONLY, FOB Seller's point of shipment.
